Cleveland® C49134 2745 Heavy Duty Taper Length Drill, 1/2 in Drill - Fraction, 0.5 in Drill - Decimal Inch, 7-3/4 in OAL, HSS, Uncoated

Cleveland® C49134 GRE C49134

Cleveland® C49134 2745 Heavy Duty Taper Length Drill, 1/2 in Drill - Fraction, 0.5 in Drill - Decimal Inch, 7-3/4 in OAL, HSS, Uncoated

Cleveland® C49134 2745 Heavy Duty Taper Length Drill, 1/2 in Drill - Fraction, 0.5 in Drill - Decimal Inch, 7-3/4 in OAL, HSS, Uncoated

  • Brand: Cleveland®
  • Mfr# : C49134
  • Item # : GRE C49134
  • UPC #: 697334491347
  • Min. Order Qty: :
  • Qty. Interval: :
# Add Customer Part #
loading
loading

Add To Cart
   Add To Product List

FEATURES

  • Run at carbide speeds
  • HSS shank and body for extra strength
  • Uncoated (bright) series are used in non-ferrous materials
  • 30 deg helix
  • -0.001 in drill diameter tolerance
  • +/-0.125 in overall length tolerance
  • +/-0.125 in flute length tolerance
  • +/-5 deg point angle tolerance

DESCRIPTION

The CLEVELAND 2727 is a carbide-tipped drill made from carbon steel with a bright finish and straight shank, designed for precise drilling in steel, stainless steel, and aluminum.

Cleveland® Taper Length Drill, Heavy Duty, Series: 2745, 1/2 in Drill - Fraction, 0.5 in Drill - Decimal Inch, 7-3/4 in Overall Length, 3-7/16 in Cutting Depth, 2 Flutes, Spiral Flute, 3-7/16 in Flute Length, 1/2 in Shank, Tanged Shank, 118 deg Point, Radial Point, Right Hand Cutting Direction, Carbide Cutting Edge, HSS, Uncoated, Applicable Materials: Alloy Steel, Cast Iron, Low Carbon Steel and Non-Ferrous Materials

SPECIFICATIONS

Type      :    Heavy Duty
Series      :    2745
Drill Size - Fraction      :    1/2 in
Drill Size - Decimal Inch      :    0.5 in
Overall Length      :    7-3/4 in
Cutting Depth      :    3-7/16 in
Number of Flutes      :    2
Flute Type      :    Spiral
Flute Length      :    3-7/16 in
Shank Size      :    1/2 in
Shank Type      :    Tanged
Point Angle      :    118 deg
Point Type      :    Radial
Cutting Direction      :    Right Hand
Cutting Edge Material      :    Carbide
Material      :    HSS
Finish      :    Uncoated
Applicable Materials      :    Alloy Steel, Cast Iron, Low Carbon Steel and Non-Ferrous Materials

APPLICATION INFO

Standard/Approvals      :    ANSI Specified
Country of Origin      :    CN
