Cleveland® C09581 2540 Heavy Duty Taper Length Drill, 5/8 in Drill - Fraction, 0.625 in Drill - Decimal Inch, 8-3/4 in OAL, HSS, Oxide Treated

Cleveland® C09581 GRE C09581

Cleveland® C09581 2540 Heavy Duty Taper Length Drill, 5/8 in Drill - Fraction, 0.625 in Drill - Decimal Inch, 8-3/4 in OAL, HSS, Oxide Treated

Cleveland® C09581 2540 Heavy Duty Taper Length Drill, 5/8 in Drill - Fraction, 0.625 in Drill - Decimal Inch, 8-3/4 in OAL, HSS, Oxide Treated

  • Brand: Cleveland®
  • Mfr# : C09581
  • Item # : GRE C09581
  • UPC #: 697334095811
  • Min. Order Qty: :
  • Qty. Interval: :
# Add Customer Part #
loading
loading

Add To Cart
   Add To Product List

FEATURES

  • Drills feature a 20% longer flute length than regular taper length drills for increased regrinds and reach
  • Steam oxide drills provide better wear life in ferrous materials
  • 30 deg helix
  • -0.0012 in drill diameter tolerance
  • 0.25/-0.125 in overall length tolerance
  • 0.25/-0.125 in flute length tolerance
  • +/-3 deg point angle tolerance

DESCRIPTION

Cleveland® Taper Length Drill, Heavy Duty, Series: 2540, 5/8 in Drill - Fraction, 0.625 in Drill - Decimal Inch, 8-3/4 in Overall Length, 3-7/16 in Cutting Depth, 2 Flutes, Spiral Flute, 3-7/16 in Flute Length, 1/2 in Shank, Tanged Shank, 118 deg Point, Notched Point, Right Hand Cutting Direction, HSS Cutting Edge, HSS, Oxide Treated, Applicable Materials: Alloy Tool Steel, Cast Iron and Stainless Steel

SPECIFICATIONS

Type      :    Heavy Duty
Series      :    2540
Drill Size - Fraction      :    5/8 in
Drill Size - Decimal Inch      :    0.625 in
Overall Length      :    8-3/4 in
Cutting Depth      :    3-7/16 in
Number of Flutes      :    2
Flute Type      :    Spiral
Flute Length      :    3-7/16 in
Shank Size      :    1/2 in
Shank Type      :    Tanged
Point Angle      :    118 deg
Point Type      :    Notched
Cutting Direction      :    Right Hand
Cutting Edge Material      :    HSS
Material      :    HSS
Finish      :    Oxide Treated
Applicable Materials      :    Alloy Tool Steel, Cast Iron and Stainless Steel

APPLICATION INFO

Standard/Approvals      :    ANSI Specified
Application      :    Automotive Applications
Country of Origin      :    US
