Milwaukee® 2203-20 Non-Contact Voltage Detector, 10 to 1000 V AC, LED Indicator, Cat IV 1000 V AC, Plastic

Milwaukee® 2203-20 MIL 2203-20

Milwaukee® 2203-20 Non-Contact Voltage Detector, 10 to 1000 V AC, LED Indicator, Cat IV 1000 V AC, Plastic

Milwaukee® 2203-20 Non-Contact Voltage Detector, 10 to 1000 V AC, LED Indicator, Cat IV 1000 V AC, Plastic


  • Brand: Milwaukee®
  • Mfr# : 2203-20
  • Item # : MIL 2203-20
  • UPC #: 045242334056
  • Min. Order Qty:
  • Qty. Interval:

FEATURES

  • Different colors identify voltage range
  • Blade-tip for checking outlets
  • Pocket clip
  • The expanded sensitivity range of 10 to 49 V offers the ability to detect voltage in common systems that would normally go undetected when using a standard voltage detector
  • These systems include LED lighting, fire detection and suppression systems, HVAC controls and security and access controls, along with many others
  • The 10 to 1000 V dual range voltage detector not only detects, but also differentiates 10 to 49 V from the standard voltage range of 50 to 1000 V
  • Automatically differentiates 10-49V and 50-1000V

DESCRIPTION

The Milwaukee 10-1000V dual range voltage detector is the first non-contact voltage detector with the ability to light up, detect, and differentiate automatically. The expanded sensitivity range of 10-49V offers the ability to detect voltage in common systems that would normally go undetected when using a standard voltage detector. These systems include: LED lighting, fire detection & suppression systems, HVAC controls, and security & access controls, along with many others. The 10-1000V dual range voltage detector not only detects, but also differentiates 10-49V from the standard voltage range of 50 to 1000 V. it does so by using a uniquely colored LED indicators and audible tones, delivering the clearest indication of these two voltage ranges. A built-in LED work light allows for increased visibility in low-lit areas, and automatic shut-off after 5 minutes helps preserve battery life. The 10-1000V dual range voltage detector is a best-in-class voltage detection solution for any electrician, HVAC technician, or facilities maintenance technician.

Milwaukee® Voltage Detector, Non-Contact, 10 to 1000 V AC, LED Indicator, AAA Alkaline Battery Power Source, Automatic Cut-Off Switch, Safety Rating: Cat IV 1000 V AC, 14 to 122 deg F, 5.92 in L x 0.68 in W x 0.91 in H Dimensions, Plastic, Red

SPECIFICATIONS

Type      :    Non-Contact
Voltage Rating      :    10 to 1000 VAC
Indicator      :    LED
Power Source      :    AAA Alkaline Battery
Switch Type      :    Automatic Cut-Off
Safety Rating      :    Cat IV 1000 VAC
Temperature Rating      :    14 to 122 deg F
Dimensions      :    5.92 in L x 0.68 in W x 0.91 in H
Material      :    Plastic
Color      :    Red

APPLICATION INFO

Application      :    Electrician, HVAC Technician and Facilities Maintenance Technician Applications
Country of Origin      :    TW
