Bahco® ERGO™ BAH2101S-140 Diagonal Side Cutting Plier With Progressive Edge, 3.7 mm Soft Wire, 2 mm Iron and 1.8 mm Piano Nominal, 16.4 mm L x 19 mm W x 8 mm THK Alloy Steel Round Jaw, 140 mm OAL

Bahco® BAH2101S-140 BAH BAH2101S-140

Bahco® ERGO™ BAH2101S-140 Diagonal Side Cutting Plier With Progressive Edge, 3.7 mm Soft Wire, 2 mm Iron and 1.8 mm Piano Nominal, 16.4 mm L x 19 mm W x 8 mm THK Alloy Steel Round Jaw, 140 mm OAL

Bahco® ERGO™ BAH2101S-140 Diagonal Side Cutting Plier With Progressive Edge, 3.7 mm Soft Wire, 2 mm Iron and 1.8 mm Piano Nominal, 16.4 mm L x 19 mm W x 8 mm THK Alloy Steel Round Jaw, 140 mm OAL

  • Brand: Bahco®
  • Mfr# : BAH2101S-140
  • Item # : BAH BAH2101S-140
  • Min. Order Qty: :
  • Qty. Interval: :
# Add Customer Part #
loading
loading

Add To Cart
   Add To Product List
  • pdf Specification Sheet https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Bahco_BAH2101S140_Specification_Sheet.pdf

FEATURES

  • Cutting radius progresses along edge in order to cut hard material such as piano wire close to the joint as well as soft materials
  • Screw joint provides excellent running and accurate alignment of cutting edges
  • Two-component ERGO insulated handles - thermoplastic surface on tough polypropylene provides superior grip
  • Round-shaped jaws give improved accessibility in confined spaces
  • Less effort required compared to conventional cutting pliers
  • Distance from joint to center of cutting edges is reduced for greater leverage and increased cutting capacity
  • Insulated side cutting pliers developed according to the scientific ERGO process for working on live equipment up to 1000V

DESCRIPTION

Bahco® ERGO™ Side Cutting Plier, Diagonal, Series: 2101S, 3.7 mm Soft Wire, 2 mm Iron and 1.8 mm Piano Nominal Capacity, Round Jaw, 16.4 mm L x 19 mm W x 8 mm THK Jaw, Alloy Steel Jaw, 140 mm Overall Length, Polypropylene/Thermoplastic Handle, Insulated: Yes, Phosphate, Applicable Materials: Iron

SPECIFICATIONS

Type      :    Diagonal
Series      :    2101S
Nominal Capacity      :    3.7 mm Soft Wire, 2 mm Iron and 1.8 mm Piano
Jaw Type      :    Round
Jaw Size      :    16.4 mm L x 19 mm W x 8 mm THK
Jaw Material      :    Alloy Steel
Overall Length      :    140 mm
Handle Material      :    Polypropylene/Thermoplastic
Insulated      :    Yes
Finish      :    Phosphate
Applicable Materials      :    Iron

APPLICATION INFO

Country of Origin      :    ES
