Williams® JHW6C05T05 Single Acting Hydraulic Cylinder, 5 ton Capacity, 1.13 in Bore, 5.08 in L Stroke, 8.7 in Retract, 1 in Dia Rod, 10000 psi Pressure
Williams® JHW6C05T05 Single Acting Hydraulic Cylinder, 5 ton Capacity, 1.13 in Bore, 5.08 in L Stroke, 8.7 in Retract, 1 in Dia Rod, 10000 psi Pressure
Williams® JHW6C05T05 Single Acting Hydraulic Cylinder, 5 ton Capacity, 1.13 in Bore, 5.08 in L Stroke, 8.7 in Retract, 1 in Dia Rod, 10000 psi Pressure
- Brand: Williams®
- Mfr# : JHW6C05T05
- Item # : WIL JHW6C05T05
- UPC #: 662459922625
- Min. Order Qty: :
- Qty. Interval: :
Specification Sheet
VIDEO LINK
FEATURES
- Rod wiper seals out dirt and contamination, collar fixture threads, two base mounting holes on most models
- High strength steel construction from gun drilled solid bar
- High flow 3/8 in NPTF couplers, collar thread protector
- One piece high grade alloy bearing for side load protection and long life
- Polyurethane cup seal provides optimum performance
- Industrial hard chrome plated ram helps prevent rust and corrosion
- Solid steel cylinder body and heavy-duty return spring provides quicker retraction
- Maximum working pressure - 10,000 psi / 700 bar
DESCRIPTION
Williams® Hydraulic Cylinder, Single Acting, Series: 6C, 5 ton, 1.13 in Bore, 5.08 in Stroke, 8.7 in Retract, 3/4-16 UNF, 1 in Rod Dia, 10000 psi, Steel Housing, 1.5 in OD x 59.5 in L Dimensions
SPECIFICATIONS
| Type | : Single Acting |
| Series | : 6C |
| Capacity | : 5 ton |
| Bore Size | : 1.13 in |
| Stroke Length | : 5.08 in |
| Retract | : 8.7 in |
| Port Size | : 3/4-16 UNF |
| Rod Diameter | : 1 in |
| Pressure Rating | : 10000 psi |
| Housing Material | : Steel |
| Dimensions | : 1.5 in OD x 59.5 in L |
APPLICATION INFO
| Application | : Lifting and Pressing Applications |
| Country of Origin | : TW |
