Enerpac® Flat-Jac® RSM-50 Low Height Single Acting Spring Return Hydraulic Cylinder, 5 ton Capacity, 1.13 in Dia Bore, 1/4 in L Stroke, 1.28 in H Retract, 1 in Dia Rod, 10000 psi
Enerpac® Flat-Jac® RSM-50 Low Height Single Acting Spring Return Hydraulic Cylinder, 5 ton Capacity, 1.13 in Dia Bore, 1/4 in L Stroke, 1.28 in H Retract, 1 in Dia Rod, 10000 psi
Enerpac® Flat-Jac® RSM-50 Low Height Single Acting Spring Return Hydraulic Cylinder, 5 ton Capacity, 1.13 in Dia Bore, 1/4 in L Stroke, 1.28 in H Retract, 1 in Dia Rod, 10000 psi
- Brand: Enerpac®
- Mfr# : RSM-50
- Item # : ENE RSM-50
- UPC #: 662005302345
- Min. Order Qty: :
- Qty. Interval: :
Instruction/Installation Manual
FEATURES
- Compact, flat design for use where other cylinders will not fit
- Mounting holes permit easy fixturing
- Hard chrome plated high quality steel plungers
- Grooved plunger ends require no saddle
- Maximum power to height ratio
DESCRIPTION
Enerpac® Flat-Jac® Hydraulic Cylinder, Low Height Single Acting Spring Return, Series: RSM, 5 ton, 1.13 in Dia Bore, 1/4 in Stroke, 1.28 in H Retract, 1 in Rod Dia, 10000 psi, Steel Housing, Baked Enamel, 2.31 x 1.63 in OD
SPECIFICATIONS
| Type | : Low Height Single Acting Spring Return |
| Series | : RSM |
| Capacity | : 5 ton |
| Bore Size | : 1.13 in Dia |
| Stroke Length | : 1/4 in |
| Retract | : 1.28 in H |
| Rod Diameter | : 1 in |
| Pressure Rating | : 10000 psi |
| Housing Material | : Steel |
| Finish | : Baked Enamel |
| Dimensions | : 2.31 x 1.63 in OD |
APPLICATION INFO
| Application | : Repositioning of Satellite Earth Station Antenna |
| Country of Origin | : CN |
