Enerpac® Flat-Jac® RCS-502 Low Height Single Acting Spring Return Hydraulic Cylinder, 50 ton Capacity, 3-1/2 in Dia Bore, 2.38 in L Stroke, 4.81 in H Retract, 2-3/4 in Dia Rod, 10000 psi
Enerpac® Flat-Jac® RCS-502 Low Height Single Acting Spring Return Hydraulic Cylinder, 50 ton Capacity, 3-1/2 in Dia Bore, 2.38 in L Stroke, 4.81 in H Retract, 2-3/4 in Dia Rod, 10000 psi
Enerpac® Flat-Jac® RCS-502 Low Height Single Acting Spring Return Hydraulic Cylinder, 50 ton Capacity, 3-1/2 in Dia Bore, 2.38 in L Stroke, 4.81 in H Retract, 2-3/4 in Dia Rod, 10000 psi
- Brand: Enerpac®
- Mfr# : RCS-502
- Item # : ENE RCS-502
- UPC #: 662005302147
- Min. Order Qty: :
- Qty. Interval: :
Instruction/Installation Manual
FEATURES
- Lightweight, low profile design for use in confined spaces
- Baked enamel finish for increased corrosion resistance
- Plunger wiper reduces contamination, extending cylinder life
- Grooved plunger end with threaded holes for mounting tilt saddles
- Plated steel plungers
- Maximum power to height ratio
DESCRIPTION
Enerpac® Flat-Jac® Hydraulic Cylinder, Low Height Single Acting Spring Return, Series: RCS, 50 ton, 3-1/2 in Dia Bore, 2.38 in Stroke, 4.81 in H Retract, 2-3/4 in Rod Dia, 10000 psi, Steel Housing, Baked Enamel, 4.88 in OD
SPECIFICATIONS
| Type | : Low Height Single Acting Spring Return |
| Series | : RCS |
| Capacity | : 50 ton |
| Bore Size | : 3-1/2 in Dia |
| Stroke Length | : 2.38 in |
| Retract | : 4.81 in H |
| Rod Diameter | : 2-3/4 in |
| Pressure Rating | : 10000 psi |
| Housing Material | : Steel |
| Finish | : Baked Enamel |
| Dimensions | : 4.88 in OD |
APPLICATION INFO
| Application | : Repositioning of Satellite Earth Station Antenna |
| Country of Origin | : CN |
