Fluke® FLUKE-177-ESFP Digital Multimeter, 1000 VDC/VAC, 10 A, 50 MOhm Measuring, 1000 V AC/DC, 10 A, 50 MOhm, Digital Display
Fluke® FLUKE-177-ESFP Digital Multimeter, 1000 VDC/VAC, 10 A, 50 MOhm Measuring, 1000 V AC/DC, 10 A, 50 MOhm, Digital Display
Fluke® FLUKE-177-ESFP Digital Multimeter, 1000 VDC/VAC, 10 A, 50 MOhm Measuring, 1000 V AC/DC, 10 A, 50 MOhm, Digital Display
- Brand: Fluke®
- Mfr# : FLUKE-177-ESFP
- Item # : FLU 177
- UPC #: 095969095198
- Min. Order Qty: :
- Qty. Interval: :
Specification Sheet
FEATURES
- Manual and automatic ranging
- Display hold and auto-hold
- Frequency and capacitance measurements
- Minimum maximum/average recording
- Closed case calibration through front panel
- Ergonomic case with integrated protective holster
- Digital 6000 count, update 4/s, bar graph 33 segments, update 40/s
- Resistance range - 600 Ohm with accuracy of (0.9% 2), 6 kOhm, 60 kOhm, 600 kOhm, 6 MOhm with accuracy of (0.9% 1), 50 MOhm with accuracy of (1.5% 3)
- Capacitance range 1000 nF, 10 uF, 100 uF with accuracy of (1.2% 2), 9999 uF with accuracy of 10% typical
- Frequency range 99.99, 999.9, 9.999, 99.99 kHz with accuracy of (0.1% 1)
- 200 hours typical alkaline
DESCRIPTION
Fluke® 177 digital multi-meter is the preferred solution for professional technicians worldwide. Independently tested for safe use in CAT IV 600 V/CAT III 1000 V environments, the Fluke® 177 is the industry standard with all the features you need to troubleshoot and repair many problems in electrical and electronic systems. The Fluke® 177 digital multi-meter gives you True-RMS™ voltage and current measurements, 6000 count resolution, manual and automatic ranging and provide frequency, capacitance, resistance, continuity and diode measurements. In addition, the Fluke® 177 provides higher 0.09 basic accuracy, a digital display with analog bar graph and backlight.
Fluke® Digital Multimeter, 1000 VDC/VAC, 10 A, 50 MOhm Measuring, 1000 V AC/DC, 10 A, 100 kHz Frequency, 50 MOhm Resistance, Safety Rating: EN 61010-1 to CAT IV 600 V AC/DC, CAT III 1000 V AC/DC, 10000 uF Capacitance, 2% + 3 (500 Hz to 1 kHz) Accuracy, Digital Display, 9 VDC Alkaline NEDA 1604/1604A Battery, Peak Hold: No, Yes Diode Test, 3.54 in W x 1.7 in D x 7.28 in H Dimensions, -10 to 50 deg C, Hard Plastic
SPECIFICATIONS
| Measuring Range | : 1000 VDC/VAC, 10 A, 50 MOhm |
| Voltage Rating | : 1000 VAC/VDC |
| Amperage Rating | : 10 A |
| Frequency Rating | : 100 kHz |
| Resistance | : 50 MOhm |
| Safety Rating | : EN 61010-1 to CAT IV 600 VAC/VDC, CAT III 1000 VAC/VDC |
| Capacitance | : 10000 uF |
| Accuracy | : 2% + 3 (500 Hz to 1 kHz) |
| Display Type | : Digital |
| Battery Type | : 9 VDC Alkaline NEDA 1604/1604A |
| Peak Hold | : No |
| Diode Test | : Yes |
| Dimensions | : 3.54 in W x 1.7 in D x 7.28 in H |
| Temperature Rating | : -10 to 50 deg C |
| Material | : Hard Plastic |
APPLICATION INFO
| Standard/Approvals | : Australian N10140 Registered|CSA Certified|ECCN 3A992|EN 61010-1|TUV File No. EN 61010|UL Listed |
| Application | : For troubleshooting and repair of electrical and electronic systems |
| Country of Origin | : US |
