Wright Tool 3206 Shape III Socket Driver Bit, 3/8 in Square Drive, 3/16 in, 1-1/4 in L Bit, ASME B107.110
Wright Tool 3206 Shape III Socket Driver Bit, 3/8 in Square Drive, 3/16 in, 1-1/4 in L Bit, ASME B107.110
Wright Tool 3206 Shape III Socket Driver Bit, 3/8 in Square Drive, 3/16 in, 1-1/4 in L Bit, ASME B107.110
- Brand: Wright Tool
- Mfr# : 3206
- Item # : WRI 3206
- UPC #: 076799032065
- Min. Order Qty: :
- Qty. Interval: :
FEATURES
- Wright drive takes full advantage of advanced CAD/CAM technology
- Improved torque load capabilities of every fastener
- Stress is distributed over a much larger area
- Leverage is improved, eliminating rounding and increasing strength
- Tool-to-fastener contact area is ten times greater than with a conventional design
- Ball locking
- 15/32 in opening side
DESCRIPTION
Wright Tool Socket Driver Bit, Shape III, Measurement System: Imperial, Square Drive, 3/8 in Drive, Hex Bit, 3/16 in Bit, 1-1/4 in Bit Length, 11/16 in Drive End Width, 1-7/8 in Overall Length, Specifications Met: ASME B107.110, Alloy Steel, Black Oxide/Polished Chrome
SPECIFICATIONS
| Type | : Shape III |
| Measurement System | : Imperial |
| Drive Type | : Square |
| Drive Size | : 3/8 in |
| Bit Type | : Hex |
| Bit Size | : 3/16 in |
| Bit Length | : 1-1/4 in |
| Drive End Width | : 11/16 in |
| Overall Length | : 1-7/8 in |
| Specifications Met | : ASME B107.110 |
| Material | : Alloy Steel |
| Finish | : Black Oxide/Polished Chrome |
APPLICATION INFO
| Standard/Approvals | : ASME B107.110 |
| Country of Origin | : US |
