Starrett® 25-881J-8 25 Series AGD Group 2 Continuous Dial Indicator, 25 mm, 0 to 100 Dial Reading, 0.01 mm, 2-1/4 in Dial, 13/64 in Dia Tip
Starrett® 25-881J-8 25 Series AGD Group 2 Continuous Dial Indicator, 25 mm, 0 to 100 Dial Reading, 0.01 mm, 2-1/4 in Dial, 13/64 in Dia Tip
Starrett® 25-881J-8 25 Series AGD Group 2 Continuous Dial Indicator, 25 mm, 0 to 100 Dial Reading, 0.01 mm, 2-1/4 in Dial, 13/64 in Dia Tip
- Brand: Starrett®
- Mfr# : 25-881J-8
- Item # : STC 25-881J-8
- UPC #: 049659646580
- Min. Order Qty: :
- Qty. Interval: :
Full Engineering Drawing
VIDEO LINK
FEATURES
- Rugged and simple unit construction with a universally fitting design
- Sharp bezel serrations for positive grip
- Unbreakable crystal
- Massive bridge for rigid bearing support
- Hardened stainless steel gears and pinions
- Non-reflecting white eggshell finish on dial
- Jewel Bearings
DESCRIPTION
The Starrett 25 Series Dial Indicator has a shockless, hardened steel gear train and jewel bearings, except where noted. It is furnished with a lug-on-center back. Antimagnetic mechanism is optional for all models. Special non-shock mechanism is available for all models except 25-109, 25-209 and 25-116. 25-881J with 8mm Stem, 0.01mm Grad.
Starrett® Dial Indicator, AGD Group 2 Continuous Dial, Series: 25 Series, 25 mm, 0 to 100 Dial, Graduations: 0.01 mm, 2-1/4 in Dial, Yellow Dial, 13/64 in Dia Tip, Stainless Steel, Satin/Eggshell
SPECIFICATIONS
| Type | : AGD Group 2 Continuous Dial |
| Series | : 25 Series |
| Measuring Range | : 25 mm |
| Dial Reading | : 0 to 100 |
| Graduations | : 0.01 mm |
| Dial Size | : 2-1/4 in |
| Dial Color | : Yellow |
| Tip Size | : 13/64 in Dia |
| Material | : Stainless Steel |
| Finish | : Satin/Eggshell |
APPLICATION INFO
| Standard/Approvals | : PROP65: This product contains a chemical known to the State of California to cause birth defects or other reproductive harm |
| Application | : For tool and die shops, machine shops and tool rooms |
| Country of Origin | : US |
