Fluke® FLUKE-77-4 Digital Multimeter, 1000 VDC/VAC, 10 A, 50 MOhm Measuring, 600 mV AC to 1000 V AC/6 to 1000 V DC, 60 mA to 10 A, 600 Ohm to 50 MOhm, Digital Display
Fluke® FLUKE-77-4 Digital Multimeter, 1000 VDC/VAC, 10 A, 50 MOhm Measuring, 600 mV AC to 1000 V AC/6 to 1000 V DC, 60 mA to 10 A, 600 Ohm to 50 MOhm, Digital Display
Fluke® FLUKE-77-4 Digital Multimeter, 1000 VDC/VAC, 10 A, 50 MOhm Measuring, 600 mV AC to 1000 V AC/6 to 1000 V DC, 60 mA to 10 A, 600 Ohm to 50 MOhm, Digital Display
- Brand: Fluke®
- Mfr# : FLUKE-77-4
- Item # : FLU 77-IV
- UPC #: 095969365239
- Min. Order Qty: :
- Qty. Interval: :
Specification Sheet
FEATURES
- Large display that makes easier to view
- Ergonomic over-molded housing with integrated probe holders
- Min/max to record signal fluctuations
- Backlight for work in dim areas
- Free your hands with the optional TPAK magnetic hanger
- Auto and manual ranging
- ANSI/ISA S82.02.01, CSA C22.21010.1, IEC 61010 to 1000 VAC measurement category III, 600 VAC measurement category IV
- Resistance range - 600 Ohm, 6 kOhm, 60 kOhm, 600 kOhm, 6 MOhm, 50 MOhm with accuracy of +/-(0.5% + 1)
- Capacitance range 1 nF, 10 uF, 100 uF with accuracy of +/-(1.2% + 2), 9999 uF with accuracy of 10%
- Frequency range 99.99 Hz, 999.9 Hz, 9.999 kHz, 99.99 kHz with accuracy of +/-(0.1% + 1)
- 400 hours typical alkaline
- Digital 6000 count, update 4/s, bar graph 33 segments display
DESCRIPTION
Fluke® 77 IV digital multi-meter has the features needed to repair most electrical and electronic problems. This meter is simple to use and has significant improvements over Fluke®'s original 70 series with more measurement functions, conformance to the latest safety standards and a much larger display that's easier to view.
Fluke® Digital Multimeter, 1000 VDC/VAC, 10 A, 50 MOhm Measuring, 600 mV AC to 1000 V AC/6 to 1000 V DC, 60 mA to 10 A, 99.99 Hz to 99.99 kHz Frequency, 600 Ohm to 50 MOhm Resistance, Safety Rating: CAT III 1000 V, CAT IV 600 V, 1 nF to 9999 uF Capacitance, +/- (2% + 2) for AC Voltage, +/- (0.3% + 1) for DC Voltage Accuracy, Digital Display, 9 VDC Alkaline, NEDA 1604/1604A V Battery, Yes Diode Test, 3.54 in W x 1.7 in D x 7.28 in H Dimensions, -10 to 50 deg C, Hard Plastic
SPECIFICATIONS
| Measuring Range | : 1000 VDC/VAC, 10 A, 50 MOhm |
| Voltage Rating | : 600 mVAC to 1000 VAC/6 to 1000 VDC |
| Amperage Rating | : 60 mA to 10 A |
| Frequency Rating | : 99.99 Hz to 99.99 kHz |
| Resistance | : 600 Ohm to 50 MOhm |
| Safety Rating | : CAT III 1000 V, CAT IV 600 V |
| Capacitance | : 1 nF to 9999 uF |
| Accuracy | : +/- (2% + 2) for AC Voltage, +/- (0.3% + 1) for DC Voltage |
| Display Type | : Digital |
| Battery Type | : 9 VDC Alkaline, NEDA 1604/1604A V |
| Diode Test | : Yes |
| Dimensions | : 3.54 in W x 1.7 in D x 7.28 in H |
| Temperature Rating | : -10 to 50 deg C |
| Material | : Hard Plastic |
APPLICATION INFO
| Standard/Approvals | : ANSI/ISA S82.02.01|CSA C22.2 No. 1010.1|ECCN 3A992|IEC 61010|TUV (EN 61010)/(N10140) Approved|UL Listed|VDE Certified |
| Application | : For measurements to repair most electrical and electronic problems |
| Country of Origin | : US |
