Wright Tool 4830 Shape II Standard Length Socket, 1/2 in Square Drive, 15/16 in, 6 Points
Wright Tool 4830 Shape II Standard Length Socket, 1/2 in Square Drive, 15/16 in, 6 Points
- Brand: Wright Tool
- Mfr# : 4830
- Item # : WRI 4830
- UPC #: 076799048301
- Min. Order Qty: :
- Qty. Interval: :
Catalog
FEATURES
- Improved torque load capabilities of every fastener
- Stress is distributed over a much larger area
- Leverage is improved, eliminating rounding and increasing strength
- Tool-to-fastener contact area is ten times greater than with a conventional design
DESCRIPTION
Wright's wide range of ratchets meet your every need: double-pawl ratchets in 3/8" and 1/2" drives provide ruggedness, extra strength, durability and fine tooth action. We also have the handles and attachments you're looking for- from extensions and spinners to universals, flex handles and the exclusive twin flex
Wright Tool Socket, Shape II Standard Length, Series, Yes Impact Rated, Measurement System, Square Drive, Drive Size, in 1/2, Socket Size, in 15/16, 1-11/16 Overall Length, Opening Depth in, in 29/32, 1-25/64 Drive End Width, Socket End Width in, in 1-25/64, Number of Points, Bolt Clearance Depth, Alloy Steel, Finish
SPECIFICATIONS
| Type | : Shape II Standard Length |
| Impact Rated | : Yes |
| Measurement System | : Imperial |
| Drive Type | : Square |
| Drive Size | : 1/2 in |
| Socket Size | : 15/16 in |
| Overall Length | : 1-11/16 in |
| Opening Depth | : 29/32 in |
| Drive End Width | : 1-25/64 in |
| Socket End Width | : 1-25/64 in |
| Number of Points | : 6 |
| Material | : Alloy Steel |
| Finish | : Black Oxide |
APPLICATION INFO
| Standard/Approvals | : ASME B107.110 |
| Country of Origin | : US |
