TTC 04-001-040 B1 Machine Chucking Reamer, 5/8 in Dia x 9 in OAL, Straight Shank, Straight Flute
TTC 04-001-040 B1 Machine Chucking Reamer, 5/8 in Dia x 9 in OAL, Straight Shank, Straight Flute
- Brand: TTC
- Mfr# : 04-001-040
- Item # : MCT 04-001-040
- UPC #: 662995200420
- Min. Order Qty: :
- Qty. Interval: :
FEATURES
- Used to produce accurate holes in a variety of normal ferrous and non-ferrous materials
- The round straight shanks may be mounted in chucks, collets or similar tool holders and may be used with a variety of standard portable or stationary machines
- Overall length, flute length and shank diameters, are sized proportionally to the cutting diameter to permit maximum rigidity throughout the cutting depth of the tool
- Combination of flute depth and shank diameter help to ensure adequate space for chips and reduce the contact area to reduce heat build-up
- Pointed with a 45 deg chamfered end that forms the cutting edges, when resharpening, this 45 deg chamfer is the only area that should be ground
- Easily resharpened
- Manufacturing method: ground from the solid
DESCRIPTION
TTC Machine Chucking Reamer, Series: Modle B1, 5/8 in Dia, 9 in Overall Length, Straight Shank, Straight Flute, 2-1/4 in Flute Length, HSS, Uncoated, Right Hand Cutting, Applicable Materials: Ferrous and Non-Ferrous Metals
SPECIFICATIONS
| Series | : B1 |
| Diameter | : 5/8 in |
| Overall Length | : 9 in |
| Shank Type | : Straight |
| Flute Type | : Straight |
| Flute Length | : 2-1/4 in |
| Material | : HSS |
| Finish | : Uncoated |
| Cutting Direction | : Right Hand |
| Applicable Materials | : Ferrous and Non-Ferrous Metals |
APPLICATION INFO
| Application | : For resizing drilled and bored holes to precise size diameters |
