TTC 07-053-016 C9 Long Flute Straight Shank Counterbore With Attached Pilot, 1/4 in Socket Head Cap Screw, 13/32 in Dia Bore, 5 in OAL, Right Hand Cutting

TTC 07-053-016 MCT 07-053-016

TTC 07-053-016 C9 Long Flute Straight Shank Counterbore With Attached Pilot, 1/4 in Socket Head Cap Screw, 13/32 in Dia Bore, 5 in OAL, Right Hand Cutting

TTC 07-053-016 C9 Long Flute Straight Shank Counterbore With Attached Pilot, 1/4 in Socket Head Cap Screw, 13/32 in Dia Bore, 5 in OAL, Right Hand Cutting

  • Brand: TTC
  • Mfr# : 07-053-016
  • Item # : MCT 07-053-016
  • UPC #: 662995213230
  • Min. Order Qty: :
  • Qty. Interval: :
# Add Customer Part #
loading
loading

Add To Cart
   Add To Product List

FEATURES

  • For general purpose applications in mild steel and non-ferrous metal

DESCRIPTION

TTC Counterbore, Long Flute Straight Shank, Series: Modle C9, 1/4 in Screw, Socket Head Cap Screw, 13/32 in Bore Dia, 5 in Overall Length, 3/8 in Shank Dia, 3 Flutes, 9/32 in Pilot Dia, Right Hand Cutting, HSS

SPECIFICATIONS

Type      :    Long Flute Straight Shank
Series      :    C9
Screw Size      :    1/4 in
Screw Type      :    Socket Head Cap
Bore Diameter      :    13/32 in
Overall Length      :    5 in
Shank Diameter      :    3/8 in
Number of Flutes      :    3
Pilot Diameter      :    9/32 in
Cutting Direction      :    Right Hand
Material      :    HSS
