Starrett® 436.1XRL-1 Mechanical Outside Micrometer, 0 to 1 in, Graduations: 0.001 in, Carbide Tip, Satin Chrome
Starrett® 436.1XRL-1 Mechanical Outside Micrometer, 0 to 1 in, Graduations: 0.001 in, Carbide Tip, Satin Chrome
Starrett® 436.1XRL-1 Mechanical Outside Micrometer, 0 to 1 in, Graduations: 0.001 in, Carbide Tip, Satin Chrome
- Brand: Starrett®
- Mfr# : 436.1XRL-1
- Item # : STC 436.1XRL-1
- UPC #: 049659679946
- Min. Order Qty: :
- Qty. Interval: :
Owners/User Manual
VIDEO LINK
FEATURES
- The most popular precision micrometers used by skilled workmen worldwide
- Accurate, rugged, and easy to use
- Advanced sleeve design with staggered lines and distinct figures for precise and easy readability
- Balanced frame and thimble design ensure easy handling
- Gracefully designed tapered frame for use in narrow slots and tight places
- Quick and easy adjustment
- Micro-lapped measuring faces
- Extremely hard and stable one-piece spindle
DESCRIPTION
Starrett 436.1 Outside Mechanical Micrometers are the most popular precision micrometers used by skilled workmen worldwide. They are accurate, rugged, and easy to use. 436.1XRL-1 features a 0-1" range, .001" graduations, and a flat, carbide anvil. The locknut is knurled ring type, with ratchet thimble. Produced with a black gloss frame finish. Furnished with a storage case. Standard Letter of Certification (SLC) is available as an optional add-on.
Starrett® Outside Micrometer, Mechanical, Series: 436.1, 0 to 1 in, +/-0.0001 in Accuracy, Graduations: 0.001 in, 0.001 in Resolution, Flat Anvil, Flat Spindle, 1/4 in Spindle Dia, Ratchet Thimble, Carbide Tip, Satin Chrome, 2-11/64 in H x 39/64 in W
SPECIFICATIONS
| Type | : Mechanical |
| Series | : 436.1 |
| Measuring Range | : 0 to 1 in |
| Accuracy | : +/-0.0001 in |
| Graduations | : 0.001 in |
| Resolution | : 0.001 in |
| Anvil Type | : Flat |
| Spindle Type | : Flat |
| Spindle Diameter | : 1/4 in |
| Thimble Type | : Ratchet |
| Material | : Carbide Tip |
| Finish | : Satin Chrome |
| Dimensions | : 2-11/64 in H x 39/64 in W |
APPLICATION INFO
| Standard/Approvals | : PROP65: This product contains a chemical known to the State of California to cause birth defects or other reproductive harm |
| Country of Origin | : US |
