Starrett® 25-2041J 25 Series AGD Group 2 Continuous Dial Dial Indicator, 2 in, 0 to 100 Dial Reading, 0.001 in, 2-1/4 in Dial

Starrett® 25-2041J STC 25-2041J

Starrett® 25-2041J 25 Series AGD Group 2 Continuous Dial Dial Indicator, 2 in, 0 to 100 Dial Reading, 0.001 in, 2-1/4 in Dial

Starrett® 25-2041J 25 Series AGD Group 2 Continuous Dial Dial Indicator, 2 in, 0 to 100 Dial Reading, 0.001 in, 2-1/4 in Dial

  • Brand: Starrett®
  • Mfr# : 25-2041J
  • Item # : STC 25-2041J
  • UPC #: 049659533095
  • Min. Order Qty: :
  • Qty. Interval: :
# Add Customer Part #
loading
loading

Add To Cart
   Add To Product List

FEATURES

  • Rugged and simple unit construction with a universally fitting design
  • Sharp bezel serrations for positive grip
  • Unbreakable crystal
  • Massive bridge for rigid bearing support
  • Hardened stainless steel gears and pinions
  • Jewel Bearings

DESCRIPTION

The Starrett 25 Series Dial Indicator with Long Range features a shockless, hardened steel gear train and is furnished with jewel bearings and lug-on-center backs. Conforms to AGD specifications except for range. Stem cap supplied as standard. Furnished with continuous reading double dial with direct reading count hands. 2.000" Range, Dial Reading 0-100, .001" Grad.

Starrett® Dial Indicator, AGD Group 2 Continuous Dial, Series: 25 Series, 2 in, 0 to 100 Dial, Graduations: 0.001 in, 2-1/4 in Dial, White Dial, Stainless Steel, Satin/Eggshell

SPECIFICATIONS

Type      :    AGD Group 2 Continuous Dial
Series      :    25 Series
Measuring Range      :    2 in
Dial Reading      :    0 to 100
Graduations      :    0.001 in
Dial Size      :    2-1/4 in
Dial Color      :    White
Material      :    Stainless Steel
Finish      :    Satin/Eggshell

APPLICATION INFO

Standard/Approvals      :    PROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP)/which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP)/which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Application      :    For tool and die shops, machine shops and tool rooms
Country of Origin      :    US
