Tridon® 53060 53-0 General Purpose Lined Hose Worm Gear Clamp, 1/2 to 7/8 in Clamp, #6 Trade, Stainless Steel Band, Plated Carbon Steel Bolt

Tridon® 53060 IDE 5306

Tridon® 53060 53-0 General Purpose Lined Hose Worm Gear Clamp, 1/2 to 7/8 in Clamp, #6 Trade, Stainless Steel Band, Plated Carbon Steel Bolt

Tridon® 53060 53-0 General Purpose Lined Hose Worm Gear Clamp, 1/2 to 7/8 in Clamp, #6 Trade, Stainless Steel Band, Plated Carbon Steel Bolt

  • Brand: Tridon®
  • Mfr# : 53060
  • Item # : IDE 5306
  • Min. Order Qty: :
  • Qty. Interval: :
# Add Customer Part #
loading
loading

Add To Cart
   Add To Product List
  • pdf Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Ideal_Tridon_57080_Catalog.pdf

FEATURES

  • Lined clamps are designed for use with silicone rubber and other soft hose applications
  • The liner protects the hose surface and prevents it from extruding or shearing through the band notches as the clamp is tightened
  • 3/8 in hose inner diameter

DESCRIPTION

Tridon® Hose Worm Gear Clamp, General Purpose Lined, Series: 53-0, Clamping Range: 1/2 to 7/8 in, #6, 1/2 in Width, 200 Grade, 5/16 in Hex Bolt, 35 in-lb, Stainless Steel Band, Plated Carbon Steel Bolt

SPECIFICATIONS

Type      :    General Purpose Lined
Series      :    53-0
Clamping Range      :    1/2 to 7/8 in
Trade Size      :    #6
Width      :    1/2 in
Bolt Size      :    5/16 in Hex
Grade      :    200
Torque Rating      :    35 in-lb
Band Material      :    Stainless Steel
Bolt Material      :    Plated Carbon Steel
