WIDIA GTD 2749991 GUN™ 5351 Spiral Point Tap, Right Hand Cutting, M10x1.5 Thread, D6 Thread Limit, Plug Chamfer, 3 Flutes, Uncoated, HSS
WIDIA GTD 2749991 GUN™ 5351 Spiral Point Tap, Right Hand Cutting, M10x1.5 Thread, D6 Thread Limit, Plug Chamfer, 3 Flutes, Uncoated, HSS
WIDIA GTD 2749991 GUN™ 5351 Spiral Point Tap, Right Hand Cutting, M10x1.5 Thread, D6 Thread Limit, Plug Chamfer, 3 Flutes, Uncoated, HSS
- Brand: WIDIA GTD
- Mfr# : 2749991
- Item # : GRE 13389
- Min. Order Qty: :
- Qty. Interval: :
Catalog
FEATURES
- Shoots chips ahead of the cutting action to reduce overloading and clogging in flutes, protecting the workpiece
- Extended life in ferrous materials
DESCRIPTION
WIDIA GTD Spiral Point Tap, Series: GUN™ 5351, Measurement System: Metric, Coarse, M10x1.5, Plug Chamfer, 3 Flutes, HSS, Uncoated, Class of Fit: 6H, Right Hand Cutting, 1-1/4 in Thread Length, 2.94 in Overall Length, 0.381 in Shank Dia, Wrought Aluminum/Cast Aluminum Alloy, Copper/Copper Alloy and Non-Metals Material Application, D6 Thread Limit
SPECIFICATIONS
| Series | : GUN™ 5351 |
| Measurement System | : Metric |
| Thread Standard | : Coarse |
| Thread Size | : M10x1.5 |
| Chamfer Type | : Plug |
| Number of Flutes | : 3 |
| Material | : HSS |
| Finish/Coating | : Uncoated |
| Class of Fit | : 6H |
| Cutting Direction | : Right Hand |
| Thread Length | : 1-1/4 in |
| Overall Length | : 2.94 in |
| Shank Diameter | : 0.381 in |
| Material Application | : Wrought Aluminum/Cast Aluminum Alloy, Copper/Copper Alloy and Non-Metals |
| Thread Limit | : D6 |
APPLICATION INFO
| Standard/Approvals | : ANSI Specified|USCTI 302A |
| Application | : For through hole in general machining applications |
| Country of Origin | : US |
