Cleveland® C27137 4001 Chucking Reamer, 25.4 mm Dia x 266.7 mm OAL, 22.19 mm Dia Straight Shank, Straight Flute
Cleveland® C27137 4001 Chucking Reamer, 25.4 mm Dia x 266.7 mm OAL, 22.19 mm Dia Straight Shank, Straight Flute
Cleveland® C27137 4001 Chucking Reamer, 25.4 mm Dia x 266.7 mm OAL, 22.19 mm Dia Straight Shank, Straight Flute
- Brand: Cleveland®
- Mfr# : C27137
- Item # : GRE C27137
- UPC #: 697334271376
- Min. Order Qty: :
- Qty. Interval: :
Catalog
FEATURES
- General purpose for a wide range of operating conditions and materials
DESCRIPTION
Cleveland® Chucking Reamer, Series: 4001, 25.4 mm Diameter, 266.7 mm Overall Length, Straight Shank, 22.19 mm Shank Diameter, 8 Flutes, Straight Flute, 69.85 mm Flute Length, HSS, Uncoated, Right Hand Cutting Direction, Applicable Materials: Alloy Steel, Aluminum, Cast Iron, Free Machining Stainless Steel, Plastic and Tool Steel
SPECIFICATIONS
| Series | : 4001 |
| Diameter | : 25.4 mm |
| Overall Length | : 266.7 mm |
| Shank Type | : Straight |
| Shank Diameter | : 22.19 mm |
| Number of Flutes | : 8 |
| Flute Type | : Straight |
| Flute Length | : 69.85 mm |
| Material | : HSS |
| Finish | : Uncoated |
| Cutting Direction | : Right Hand |
| Applicable Materials | : Alloy Steel, Aluminum, Cast Iron, Free Machining Stainless Steel, Plastic and Tool Steel |
APPLICATION INFO
| Standard/Approvals | : ANSI Specified|DIN 338 |
| Application | : Through Hole Applications |
| Country of Origin | : US |
