Mitutoyo 950-317 Rectangular Head Digital Protractor Without Data Output, 360 deg Measuring, 153 mm L, Aluminum Frame
Mitutoyo 950-317 Rectangular Head Digital Protractor Without Data Output, 360 deg Measuring, 153 mm L, Aluminum Frame
Mitutoyo 950-317 Rectangular Head Digital Protractor Without Data Output, 360 deg Measuring, 153 mm L, Aluminum Frame
- Brand: Mitutoyo
- Mfr# : 950-317
- Item # : MTI 950-317
- UPC #: 603908277231
- Min. Order Qty: :
- Qty. Interval: :
Catalog
FEATURES
- These digital protractors present inclination values on an easy to read liquid crystal display
- The measurements are generated by an electronic gravity sensor and processed by the latest low power electronic circuit technology
- Reading hold
- Simple calibration requiring no special fixtures
- Display remains upright to view at all angles
DESCRIPTION
Mitutoyo Digital Protractor, Rectangular Head, Series: 950, 360 deg Measuring, 153 mm Length, +/-0.1 deg: +/-10 deg Level/Plumb, +/-0.2 deg Maximum Error Accuracy, Aluminum Frame
SPECIFICATIONS
| Type | : Rectangular Head |
| Series | : 950 |
| Measuring Range | : 360 deg |
| Length | : 153 mm |
| Accuracy | : +/-0.1 deg: +/-10 deg Level/Plumb, +/-0.2 deg Maximum Error |
| Material | : Aluminum Frame |
APPLICATION INFO
| Application | : For measurement of flatness, squareness and angularity |
| Country of Origin | : US |
