Tridon® 47010-51 Flex-Gear® 47 Constant Tension Light Duty Spring Hose Worm Drive Clamp, 9/16 to 1-1/16 in Clamp, #10 Trade, Stainless Steel Band, 410 Stainless Steel Bolt
Tridon® 47010-51 Flex-Gear® 47 Constant Tension Light Duty Spring Hose Worm Drive Clamp, 9/16 to 1-1/16 in Clamp, #10 Trade, Stainless Steel Band, 410 Stainless Steel Bolt
Tridon® 47010-51 Flex-Gear® 47 Constant Tension Light Duty Spring Hose Worm Drive Clamp, 9/16 to 1-1/16 in Clamp, #10 Trade, Stainless Steel Band, 410 Stainless Steel Bolt
- Brand: Tridon®
- Mfr# : 47010-51
- Item # : IDE 4701051
- Min. Order Qty: :
- Qty. Interval: :
Catalog
FEATURES
- Belleville spring and clamp construction is built to respond to constant temperature fluctuations
- The larger, heavier-gauge, precision-formed springs provide higher rates of band tension and adjustment for a more dependable seal
- Inner liner protects against shearing of the hose surfaces
- 300 Stainless steel spring
- 3/8 to 5/8 in hose inner diameter
- 300 Stainless steel housing
- 9/16 in 300 stainless steel lined band
DESCRIPTION
Flex-Gear® clamps use a Belleville spring design to eliminate "cold flow" leakage that adjusts with the hose and fitting to maintain constant tension on the connection, eliminating leak paths. Flex-Gear® clamps are an excellent choice for fluctuating temperature applications and thermal compensation.
Tridon® Hose Worm Drive Clamp, Constant Tension Light Duty Spring, Series: Flex-Gear® 47, Clamping Range: 9/16 to 1-1/16 in, #10, 9/16 in Width, Grade 300, 5/16 in Hex Bolt, 50 in-lb, Stainless Steel Band, 410 Stainless Steel Bolt
SPECIFICATIONS
| Type | : Constant Tension Light Duty Spring |
| Series | : Flex-Gear® 47 |
| Clamping Range | : 9/16 to 1-1/16 in |
| Trade Size | : #10 |
| Width | : 9/16 in |
| Bolt Size | : 5/16 in Hex |
| Grade | : 300 |
| Torque Rating | : 50 in-lb |
| Band Material | : Stainless Steel |
| Bolt Material | : 410 Stainless Steel |
