Reelcraft® 5635 OLP 5000 Low Pressure Premium Duty Hose Reel With Hose, 3/8 in ID x 3/5 in OD x 35 ft L Hose, 300 psi Pressure, 14 in Dia x 2-1/2 in W Reel, Domestic
Reelcraft® 5635 OLP 5000 Low Pressure Premium Duty Hose Reel With Hose, 3/8 in ID x 3/5 in OD x 35 ft L Hose, 300 psi Pressure, 14 in Dia x 2-1/2 in W Reel, Domestic
Reelcraft® 5635 OLP 5000 Low Pressure Premium Duty Hose Reel With Hose, 3/8 in ID x 3/5 in OD x 35 ft L Hose, 300 psi Pressure, 14 in Dia x 2-1/2 in W Reel, Domestic
- Brand: Reelcraft®
- Mfr# : 5635 OLP
- Item # : REE 5635-OLP
- UPC #: 699567000150
- Min. Order Qty: :
- Qty. Interval: :
Catalog
FEATURES
- Reinforced steel - the robotically welded steel base offers maximum strength and consistent quality
- All steel components are powder coated for maximum corrosion resistance
- Full flow stress free swivel design - the full flow swivel combines the highest grade seal design and materials with bearing areas to insure maximum service life
- The hose is plumbed into the base to eliminate the risk of undue stress on the swivel
- Long life drive spring - declutching arbor virtually eliminates possibility of spring damage due to reverse winding
- Only the highest quality spring steel is used and conditioned to insure there are no imperfections offering maximum service life
- Quiet speed latch - the latch cam is designed for reliable quiet operation
- 1/4 in MNPT hose outlet
- 3/8 in FNPT reel inlet
- 150 deg F maximum temperature rating
DESCRIPTION
Series 4000, 5000 and 5005 reels are all steel construction and compact for a wide range of applications with critical space requirements. A full flow shaft and swivel assures maximum product delivery. Guide arm adjusts to two positions.
Reelcraft® Hose Reel, Low Pressure Premium Duty, Series: 5000, 3/8 in ID x 3/5 in OD x 35 ft L Hose, 300 psi Pressure, 14 in Reel Diameter, 2-1/2 in Reel Width, Retractable Spring Drive, Ceiling/Floor/Truck Bed/Wall Mounting, Brass/Copper/Zinc Dichromate Swivel, Buna-N Seal, 14-3/8 in H x 14 in W x 6-1/8 in D Dimensions, Reinforced Stainless Steel, Powder Coated, Red, Domestic
SPECIFICATIONS
| Type | : Low Pressure Premium Duty |
| Series | : 5000 |
| Hose Capacity | : 3/8 in ID x 3/5 in OD x 35 ft L |
| Pressure Rating | : 300 psi |
| Reel Diameter | : 14 in |
| Reel Width | : 2-1/2 in |
| Drive Type | : Retractable Spring |
| Mounting Type | : Ceiling/Floor/Truck Bed/Wall |
| Swivel Material | : Brass/Copper/Zinc Dichromate |
| Seal Type | : Buna-N |
| Dimensions | : 14-3/8 in H x 14 in W x 6-1/8 in D |
| Material | : Reinforced Stainless Steel |
| Finish | : Powder Coated |
| Color | : Red |
| Domestic/Import | : Domestic |
APPLICATION INFO
| Standard/Approvals | : PROP65: Cancer and Reproductive Harm www.P65Warnings.ca.gov |
| Application | : Air and Water Applications |
| Country of Origin | : US |
