Wright Tool 62-17MM Shape IV Driver Socket Bit, 3/4 in Square Drive, 17 mm, 35 mm L Bit, ASME B107.110
Wright Tool 62-17MM Shape IV Driver Socket Bit, 3/4 in Square Drive, 17 mm, 35 mm L Bit, ASME B107.110
Wright Tool 62-17MM Shape IV Driver Socket Bit, 3/4 in Square Drive, 17 mm, 35 mm L Bit, ASME B107.110
- Brand: Wright Tool
- Mfr# : 62-17MM
- Item # : WRI 62-17MM
- UPC #: 076799728739
- Min. Order Qty: :
- Qty. Interval: :
FEATURES
- Pin locking
- 30.16 mm socket end width
- 34.93 mm opening depth
- 6581 Ret ring
- 6 point
DESCRIPTION
Wright Tool Driver Socket Bit, Shape IV, Yes Impact Rated, Measurement System: Metric, Square Drive, 3/4 in Drive, Hex Bit, 17 mm Bit, 35 mm Bit Length, 41.28 mm Drive End Width, 83.34 mm Overall Length, Specifications Met: ASME B107.110, Hot Forged Alloy Steel, Black Oxide
SPECIFICATIONS
| Type | : Shape IV |
| Impact Rated | : Yes |
| Measurement System | : Metric |
| Drive Type | : Square |
| Drive Size | : 3/4 in |
| Bit Type | : Hex |
| Bit Size | : 17 mm |
| Bit Length | : 35 mm |
| Drive End Width | : 41.28 mm |
| Overall Length | : 83.34 mm |
| Specifications Met | : ASME B107.110 |
| Material | : Hot Forged Alloy Steel |
| Finish | : Black Oxide |
APPLICATION INFO
| Standard/Approvals | : ASME B107.110 |
| Country of Origin | : US |
