Tridon® 58188-52 Snaplock® 58-0 Quick Release Hose Worm Drive Clamp, 2 to 12-1/4 in Clamp, #188 Trade, Stainless Steel Band, 410 Stainless Steel Bolt
Tridon® 58188-52 Snaplock® 58-0 Quick Release Hose Worm Drive Clamp, 2 to 12-1/4 in Clamp, #188 Trade, Stainless Steel Band, 410 Stainless Steel Bolt
Tridon® 58188-52 Snaplock® 58-0 Quick Release Hose Worm Drive Clamp, 2 to 12-1/4 in Clamp, #188 Trade, Stainless Steel Band, 410 Stainless Steel Bolt
- Brand: Tridon®
- Mfr# : 58188-52
- Item # : IDE 5818852
- Min. Order Qty: :
- Qty. Interval: :
Catalog
FEATURES
- Quick release worm drive clamps are good for closed system applications where the clamp must be disengaged to be applied
- The swivel action locking of screw to band makes installation and removal much faster
- 200 Stainless steel housing
- 410 Stainless steel bridge
- 2 to 11-1/4 in hose inner diameter
- Bulk pack
DESCRIPTION
Tridon® Hose Worm Drive Clamp, Quick Release, Series: Snaplock® 58-0, Clamping Range: 2 to 12-1/4 in, #188, 9/16 in Width, 200 Grade, 3/8 in Hex Bolt, 30 in-lb, Stainless Steel Band, 410 Stainless Steel Bolt
SPECIFICATIONS
| Type | : Quick Release |
| Series | : Snaplock® 58-0 |
| Clamping Range | : 2 to 12-1/4 in |
| Trade Size | : #188 |
| Width | : 9/16 in |
| Bolt Size | : 3/8 in Hex |
| Grade | : 200 |
| Torque Rating | : 30 in-lb |
| Band Material | : Stainless Steel |
| Bolt Material | : 410 Stainless Steel |
