TTC 01-003-003 A3 Series Surface Treated Jobber Length Drill Bit, C Drill - Letter, 0.242 in Drill - Decimal Inch, 118 deg Point, HSS, Oxide Treated

TTC 01-003-003 MHT 01-003-003

TTC 01-003-003 A3 Series Surface Treated Jobber Length Drill Bit, C Drill - Letter, 0.242 in Drill - Decimal Inch, 118 deg Point, HSS, Oxide Treated

TTC 01-003-003 A3 Series Surface Treated Jobber Length Drill Bit, C Drill - Letter, 0.242 in Drill - Decimal Inch, 118 deg Point, HSS, Oxide Treated

  • Brand: TTC
  • Mfr# : 01-003-003
  • Item # : MHT 01-003-003
  • UPC #: 662995704030
  • Min. Order Qty: :
  • Qty. Interval: :
# Add Customer Part #
loading
loading

Add To Cart
   Add To Product List

FEATURES

  • Surface treatment increases abrasion resistance, reducing the amount of chip welding and improving chip flow
  • 118 deg normal point suitable for most normal, general purpose, drilling applications
  • 135 deg split point suitable for drilling high tensile strength, low machinability, ferrous materials, such as tougher alloy and harder stainless steels
  • Have a heavier web construction that offers greater rigidity and strength to better resist any increased torque
  • Self-centering and reduces the thrust required in drilling tougher materials

DESCRIPTION

TTC Jobber Length Drill Bit, Surface Treated, Series: Modle A3 Series, Imperial, C Drill, 0.242 in Drill, 4 in Overall Length, 2 Flutes, Spiral Flute, Straight Shank, 118 deg Point, Standard Point, Right Hand Cutting, HSS Cutting Edge, HSS, Oxide Treated, Applicable Materials: Steel, Cast Steel, Cast Iron, Stainless Steels and Other Alloyed or Non-Alloyed Ferrous Metals

SPECIFICATIONS

Type      :    Surface Treated
Series      :    A3 Series
Drill Diameter Measurement System      :    Imperial
Drill Size - Letter      :    C
Drill Size - Decimal Inch      :    0.242 in
Overall Length      :    4 in
Number of Flutes      :    2
Flute Type      :    Spiral
Shank Type      :    Straight
Point Angle      :    118 deg
Point Type      :    Standard
Cutting Direction      :    Right Hand
Cutting Edge Material      :    HSS
Material      :    HSS
Finish      :    Oxide Treated
Applicable Materials      :    Steel, Cast Steel, Cast Iron, Stainless Steels and Other Alloyed or Non-Alloyed Ferrous Metals

APPLICATION INFO

Application      :    For general purpose and heavy duty drilling operations
