The Square shoulder milling insert APFT1604PDTR-D15 MP1500 features two cutting edges and a single-sided design. With a clearance angle major of 11 degrees and an insert rake angle of 8 degrees, it is designed for difficult applications with an average chip thickness of 0.15 mm. The insert has a corner radius of 0.8 mm and a wiper edge length of 1.2 mm. It is made from Carbide CVD grade MP1500. The cutting geometry type is classified as D15. The main application area includes cast irons and hard materials, with partial applicability to steel. This product can be recycled. Get in contact with your sales representative to discuss next steps for more circularity. Check out more products for machine side or workpiece side options within our range to complement this product. With our complementing services, you can make the most of your tool. Download the Seco Assistant to get access to comprehensive tooling information. This text was generated and translated with the assistance of AI and may contain inaccuracies.

Seco Milling Insert, APFT Insert, 1604 Insert, Parallelogram, 4.95 mm Thickness, 16.5 mm Length, D15 Chipbreaker, 0.8 mm Corner Radius, Manufacturer's Grade: MP1500, ANSI Code: APFT1604PDTR-D15 MP1500, Right Hand, Carbide, TiCN/Al2O3, Cast Iron, Non-Ferrous Metals, Plastics and Tough-to-Machine Materials Material Application
