Chicago-Latrobe® 53434 190C Silver & Deming Drill, 17/32 in Drill - Fraction, 0.5312 in Drill - Decimal Inch, 1/2 in Shank, M42 HSS-Co 8

Chicago-Latrobe® 53434 GRE 53434

Chicago-Latrobe® 53434 190C Silver & Deming Drill, 17/32 in Drill - Fraction, 0.5312 in Drill - Decimal Inch, 1/2 in Shank, M42 HSS-Co 8

Chicago-Latrobe® 53434 190C Silver & Deming Drill, 17/32 in Drill - Fraction, 0.5312 in Drill - Decimal Inch, 1/2 in Shank, M42 HSS-Co 8

  • Brand: Chicago-Latrobe®
  • Mfr# : 53434
  • Item # : GRE 53434
  • UPC #: 662355534342
  • Min. Order Qty: :
  • Qty. Interval: :
# Add Customer Part #
loading
loading

Add To Cart
   Add To Product List
  • pdf Catalog https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Chicago_Latrobe_57830_Catalog.pdf

FEATURES

  • Manufactured from cobalt premium high speed steel for use in highly abrasive applications
  • Standard 6 in overall length and 3-1/8 in flute length for increased rigidity, less deflection and better hole accuracy
  • Standardized lengths result in minimal adjustment during tool changes in screw machines and machining centers
  • Ideal for portable drilling due to increased rigidity
  • 118 deg split point for easier, more precise penetration
  • Three flats on shank for tighter chucking
  • Straw finish adds lubricity and easily identifies cobalt drills

DESCRIPTION

Chicago-Latrobe® Silver & Deming Drill, Series: 190C, 17/32 in Drill - Fraction, 0.5312 in Drill - Decimal Inch, 6 in Overall Length, 3-1/8 in Cutting Depth, 2 Flutes, Spiral Flute, 3-1/8 in Flute Length, 1/2 in Shank, Reduced Shank, 118 deg Point, Split Point, Right Hand Cutting Direction, M42 HSS-Co 8 Cutting Edge, M42 HSS-Co 8, Gold/Straw Oxide, Applicable Materials: Alloy Steel, Carbon Steel and Cast Iron

SPECIFICATIONS

Series      :    190C
Drill Size - Fraction      :    17/32 in
Drill Size - Decimal Inch      :    0.5312 in
Overall Length      :    6 in
Cutting Depth      :    3-1/8 in
Number of Flutes      :    2
Flute Type      :    Spiral
Flute Length      :    3-1/8 in
Shank Size      :    1/2 in
Shank Type      :    Reduced
Point Angle      :    118 deg
Point Type      :    Split
Cutting Direction      :    Right Hand
Cutting Edge Material      :    M42 HSS-Co 8
Material      :    M42 HSS-Co 8
Finish      :    Gold/Straw Oxide
Applicable Materials      :    Alloy Steel, Carbon Steel and Cast Iron

APPLICATION INFO

Application      :    General Purpose Applications
