DESTACO 503-MB 500 Series Heavy Duty Vertical Hold-Down Toggle Locking Clamp, Forged Alloy Steel, 1500 lb, 69.9 mm
DESTACO 503-MB 500 Series Heavy Duty Vertical Hold-Down Toggle Locking Clamp, Forged Alloy Steel, 1500 lb, 69.9 mm
DESTACO 503-MB 500 Series Heavy Duty Vertical Hold-Down Toggle Locking Clamp, Forged Alloy Steel, 1500 lb, 69.9 mm
- Brand: DESTACO
- Mfr# : 503-MB
- Item # : DST 503-MB
- Min. Order Qty: :
- Qty. Interval: :
Specification Sheet
FEATURES
- These heavy duty clamps can be completely configured to meet the specifications of the application
- They allow the designer complete flexibility to position the base, handle and clamp arm
- Hardened pivot pins and bushings
- Weldable clamping arm
- Bar opens 200 deg to clear work area
- Modular design
DESCRIPTION
DESTACO Toggle Locking Clamp, Heavy Duty Vertical Hold-Down, Series: 500 Series, 1500 lb Holding, 69.9 mm Height Under Arm, 69.85 mm Overall Height, 200 deg Bar Opening, Swivel Base, Forged Alloy Steel, Oxide
SPECIFICATIONS
| Type | : Heavy Duty Vertical Hold-Down |
| Series | : 500 Series |
| Holding Capacity | : 1500 lb |
| Height Under Arm | : 69.9 mm |
| Overall Height | : 69.85 mm |
| Bar Opening | : 200 deg |
| Base Type | : Swivel |
| Material | : Forged Alloy Steel |
| Finish | : Oxide |
APPLICATION INFO
| Application | : Assembly and Welding |
| Country of Origin | : TH |
